Specifications :
| Model | LILIN AHD-765A3.6 |
| Resolution | 5 MEGAPIXEL |
| Image Sensor | 1/2.9″ CMOS Image Sensor |
| Scanning System | Progressive Scan |
| Min. illumination | 0.03 Lux / F1.8, 0 Lux (IR On) |
| Shutter Time | Auto:1/60(1/50)S – 1/50,000S; Manual:1/30(1/25)S, 1/60(1/50)S, FLK, 1/240S, 1/480S, 1/1,000S, 1/2,000S, 1/5,000S, 1/10,000S, 1/50,000S |
| Lens | 3.6mm |
| Iris | F2.0 |
| Angle of View | 72.2°(H), 52.9°(V), 94.3°(D) |
| Effective Pixels | 1,984 (H) × 1,105 (V) |
| Auto Gain Control | Auto (16 Steps) |
| White Blance | ATW / AWC / INDOOR / OUTDOOR / MANUAL / AWB |
| Noise Reduction | 2DNR & 3DNR |
| Privacy Masking | 4 Zones |
| IP Rating | IP 68 |
| IR Radiant Distance | 20M |
| Video Output | AHD 5MP |
| Operating Temperature | -10? – +50? (14°F – 122°F) |
| Dimensions | 78mm (W) x 66.5mm (H) x 88mm (D) |
| Weight | 325g |
| Power | DC12V ±10%, 3.8W |
; : –
